Linear Spot + Track Spot

Linear Spot + Track Spot

Linear Spot Beam Angle - 15°

Track Light Beam Angle - 15° / 33°
9,964
Product Code : LSTS
Availability:
Track Wattage & Beam
Profile Color
Track Light Fixture
Linear Spot Color Temp.
Track Light Color Temp.
Driving System
Select Qty:
Add to Wish List

* Shipping charges additional to be paid at the time of receiving delivery. To know more chat with us.

Description

Profile
ModelH3550 Profile - Linear Spot Track Spot
MountingSuspended, Surface
MaterialAluminum
IP RateIP20
MacAdam ellipseinitial ≤ 3 MacAdam
Driving System
RF, RF + Dual Color
System Warranty
1 Year

Linear Spot
Input Power
24 Watt
Beam Angle
15°
Typ. Color Temp
 2700K / 3000K / 4000K / 6000K / 2700K-5000K (Dual Color)
Lumen
2097 / 2184 / 2181 / 2268 lm
IP RateIP20
CRI
80
System Warranty
1 Year


Track Light

MaterialAluminum
Power
08Watt / 12 Watt
Beam Angle
15° / 33°
Fixture Color
White/ Black/ White - Black
Dimension
Ø57 mm - Ht.120 mm
Color Temperature
3000K /4000K / 5000K / 6000K / 2700K-5000K (Dual Color)
Lumen
1305 / 1318 / 1383 / 1436 lm
MacAdam ellipse
initial ≤ 3 MacAdam
CRI92+
System Warranty
1 Year


Downloads

 PDF           DWG


3D             IES             LDT
