Description
- Extruded Aluminum Housing
- SS 304 Grade Trim & fasteners for corrosion resistance
- Extruded Aluminum Heatsink Used For Better Heat Dissipation
- High Power LEDs Used
- Polycarbonate lens Used
- Watertight Silicone Rubber Gasket for IP protection
- SS cable Gland Used
- Suitable for drive-over, Load is transferred by the housing to the foundation
- External Constant Voltage Power Supply
- Recessing Box for easy Installation Inground
- IP68 Connector
- Mounting: Inground Recessed
USP
-Unique Vertical LED Source placement Design to face front for more Light O/P & Wide Path Coverage.
-Light Source Placed Well inside with high Cutoff angle to avoid direct Glare.
-High Power LEDs Under Driven For High Efficacy , Less Thermals & Long Life.
-Earthing Safe Connection For Shockproof Application.
-Easy Installtion with PVC recessing box.
Mechanical Details:
Material
| Extruded Aluminium Housing & Stainless steel Trim
|
Finish
| Chrome
|
|---|
| Dimension | Ø79 X 96mm (With Recessing Box Height - 104 mm)
|
|---|
Cutout (Recessing Box)
| ø55mm
|
|---|
Lens
| PC Lens
|
Gasket
| Silicone gasket
|
Cable
| 3C X 0.75 Sqmm Cable(L - 300mm)
|
Cable Entry
| Single Entry
|
Cable Gland
| SS
|
Power Supply
| Built - IN IP68 Potted Driver
|
IP Rating
| IP67
|
| Weight | 0.35Kg
|
Technical Details:
Lamp
| LED
|
| Input Power | 4 X 2W
|
Color Temperature
| 3000 K
|
Lumen
| 441 LM
|
Efficacy
| 55 LM/W
|
|---|
Beam Angle
| 4 X (H-81°XV-21°)
|
|---|
Input Voltage
| 220-240VAC
|
|---|
Driving System
| Constant Current
|
Dimming Type
| ON / OFF
|
CRI
| 80+
|
MacAdam
| <3
|
Operating Temperature
| -10 to 50°C
|
LED Life
| L70 at 50000 burning Hours
|
Safety Class
| Class I
|
System Warranty
| 1 Years
|
| Model | Fixture Color | Power(W) | CCT(K) | Luminous Flux(LM) | Beam Angle(Degree) | Control | Cable |
IGRS4X02W30CC-
| S-Stainless Steel | 08W | 6 X 1.3W LED
(3000K) | 394 lm | Wide - 4 X (H-81°XV-21°)
| CC - Constant Current | - Single Cable |
W - H-81° - V- 21°
