Description
-Extruded Aluminium Housing With Aluminium Endcap
-Hard polyurethane Light compartment Used With Silicone Endcaps
-SS cable Gland Used
-Suitable for Walk-over , Drive-over
-External Constant Voltage Power Supply
-Linear light design
-Homogeneous and dots-free
-Mounting : Inground Recessed
-Protection : IP67
USP:
*50mm Width Hard polyurethane Housing for Walkover & DriveOver.
*Separatable polyurethane Light Compartment From Extrusion For Easy Servicing.
*Easy Installation In Ground With Aluminium Extrusion.
*Diffused Soft Light Eliminating Glare.
*SELV 24VDC For Shock Proof Application.
Mechanical Details
Material
| Extruded Aluminium & polyurethane Encapsulation
|
Size
| 1000*50*52.4mm
|
Diffuser
| Milky Diffused
|
Endcap
| Aluminium Endcap - For Profile Silicone Endcap - For Diffuser |
Cable Entry
| Single / Loop - In Loop - Out
|
Cable Gland
| SS
|
Power Supply
| External SMPS 24VDC
|
Connector
| IP67 Wired Male Connector(L-300mm) IP67 Wired Female Connector(L-300mm) |
IP Rating
| IP67
|
Weight
| 1.5Kg / Meter
|
Technical Details
Lamp
| Lamp |
| Input Power | 40W
|
Color Temperature
| 3000K
|
Lumen
| 2640lm
|
Efficacy
| 66lm/w
|
Beam Angle
| 107°
|
|---|
Input Voltage
| 24VDC
|
|---|
Driving System
| Constant Voltage
|
|---|
Dimming Type
| ON / OFF
|
CRI
| 80+
|
|---|
MacAdam
| <5
|
Operating Temperature
| -10 to 50°C
|
LED Life
| L70 at 50000 burning Hours
|
Safety Class
| Class III(SELV)
|
System Warranty
| 1 Year |
Accessories
*M685 IP68 Straight Connector
*SMPS 60W
